BP0159-0191-0127-BSTH - Datasheet
MBA
Category Information
Bushes - Unflanged - Bronze - SinteredSintered Bronze Unflanged Bushes. Oil impregnated sintered bronze bushes.
- An expanded range may be available on special order. Please enquire.
- Precision items show an allowable Load Speed Rating in Newtons times RPM.
Product Data
- Nominal Inside Diameter (d)
:
15.875
mm
+ 0.025 / + 0.051
(Equiv. 0.625 in.) - Nominal Outside Diameter (D)
19.050
mm
+ 0.051 / + 0.076
(Equiv. 0.75 in.) - Length (s)
12.700
mm
+/- 0.127
(Equiv. 0.5 in.) - Material Bronze SAE 841 Sintered
Product Compliance and Data
Additional Resources
- DU Bush Material Information
- General Bushes Catalogue
- Sintered Bronze Products Catalogue
- Solid Bronze Bushes catalogue
Cross References
- 6391K241
- Oilite® AA-710-27
- Oilite® AA710-27
- Oilite® AP710-27
- Bunting® B-1012-4
- Reid Tool® BNT-159
- Bunting® EP101208
- Daemar P-62-4
- Small Parts SBB-10-8
- BNT159
- SBB108
- BP015901910127BS
- BP015901910127BS-SH
- BP015901910127BSSH
- QT1741
- QT174-1
- P624
- AP71027
- B10124
- AA71027
