Retaining Rings - External - Circlips - Standard - Carbon Steel

Retaining Rings -> External -> Circlips -> Standard -> Carbon Steel
Shaft Diameter (Ds) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip ID (A) Radial Wall (S) Approx. Groove Width (W) Indicative
External Retaining Rings - 198x4x193 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
198.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
193.00
mm
+ 0.00 / - 0.72
(Equiv. 7.598 in.)
Approx. Loose Circlip ID (A)
187.50
mm
Groove Width (W)
4.15
mm
External Retaining Rings - 198x4x193 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-19800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
Shaft Diameter (Ds) Clip Thickness (T) Groove Dia. (Dg) Approx. Loose Circlip ID (A) Indicative
External Retaining Rings - 198x4x193 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
198.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
193.00
mm
+ 0.00 / - 0.72
(Equiv. 7.598 in.)
Approx. Loose Circlip ID (A)
187.50
mm
External Retaining Rings - 198x4x193 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 4.15 mm    Standard: DIN471
Part Number: CCE-19800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 200x5x195 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
200.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
195.00
mm
+ 0.00 / - 0.72
(Equiv. 7.677 in.)
Approx. Loose Circlip ID (A)
190.50
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 200x5x195 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: Heavy Duty Variation DIN471 table 2
Part Number: CCE-20000H-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 200x5x195 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
200.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
195.00
mm
+ 0.00 / - 0.72
(Equiv. 7.677 in.)
Approx. Loose Circlip ID (A)
190.50
mm
External Retaining Rings - 200x5x195 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: Heavy Duty Variation DIN471 table 2
Part Number: CCE-20000H-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 158.75x3.18x152 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
158.75
mm
Clip Thickness (T)
3.18
mm
+/- 0.127
(Equiv. 0.125 in.)
Groove Dia. (Dg)
152.00
mm
+/- 0.204
(Equiv. 5.984 in.)
Approx. Loose Circlip ID (A)
149.00
mm
Groove Width (W)
4.40
mm
External Retaining Rings - 158.75x3.18x152 mm - Carbon Steel
Material: Carbon Steel    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 13
Part Number: CCE-15875-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$166.23 AUD
$197.87 AUD $166.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 158.75x3.18x152 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
158.75
mm
Clip Thickness (T)
3.18
mm
+/- 0.127
(Equiv. 0.125 in.)
Groove Dia. (Dg)
152.00
mm
+/- 0.204
(Equiv. 5.984 in.)
Approx. Loose Circlip ID (A)
149.00
mm
External Retaining Rings - 158.75x3.18x152 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.40 mm    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 13
Part Number: CCE-15875-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$166.23 AUD
$197.87 AUD $166.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 202x5x196 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
202.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.10
(Equiv. 0.197 in.)
Groove Dia. (Dg)
196.00
mm
+ 0.00 / - 0.72
(Equiv. 7.717 in.)
Approx. Loose Circlip ID (A)
190.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 202x5x196 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-20200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 202x5x196 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
202.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.10
(Equiv. 0.197 in.)
Groove Dia. (Dg)
196.00
mm
+ 0.00 / - 0.72
(Equiv. 7.717 in.)
Approx. Loose Circlip ID (A)
190.00
mm
External Retaining Rings - 202x5x196 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-20200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 160x4x155 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
160.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
155.00
mm
+ 0.00 / - 0.63
(Equiv. 6.102 in.)
Approx. Loose Circlip ID (A)
151.00
mm
Groove Width (W)
4.15
mm
External Retaining Rings - 160x4x155 mm - Carbon Steel
Material: Carbon Steel    Clearance on Shaft (C1): 182.00 mm    Clearance in Groove (C1): 188.00 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Part Number: CCE-16000-C (Each)
5 Available Now | Further orders can be expected around Tue, Sep 01, 2026
$16.41 AUD
$28.16 AUD $16.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Larger quantities than the 5 available can be backordered.
External Retaining Rings - 160x4x155 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
160.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
155.00
mm
+ 0.00 / - 0.63
(Equiv. 6.102 in.)
Approx. Loose Circlip ID (A)
151.00
mm
External Retaining Rings - 160x4x155 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.15 mm    Clearance on Shaft (C1): 182.00 mm    Clearance in Groove (C1): 188.00 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Part Number: CCE-16000-C (Each)
5 Available Now | Further orders can be expected around Tue, Sep 01, 2026
$16.41 AUD
$28.16 AUD $16.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

5 Available Now. Backorder if more than 5.
External Retaining Rings - 205x5x199 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
205.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
199.00
mm
+ 0.00 / - 0.72
(Equiv. 7.835 in.)
Approx. Loose Circlip ID (A)
193.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 205x5x199 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-20500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 205x5x199 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
205.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
199.00
mm
+ 0.00 / - 0.72
(Equiv. 7.835 in.)
Approx. Loose Circlip ID (A)
193.00
mm
External Retaining Rings - 205x5x199 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-20500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 207x5x201 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
207.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
201.00
mm
+ 0.00 / - 0.72
(Equiv. 7.913 in.)
Approx. Loose Circlip ID (A)
193.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 207x5x201 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-20700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 207x5x201 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
207.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
201.00
mm
+ 0.00 / - 0.72
(Equiv. 7.913 in.)
Approx. Loose Circlip ID (A)
193.00
mm
External Retaining Rings - 207x5x201 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-20700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 208x5x202 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
208.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
202.00
mm
+ 0.00 / - 0.72
(Equiv. 7.953 in.)
Approx. Loose Circlip ID (A)
193.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 208x5x202 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-20800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 208x5x202 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
208.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
202.00
mm
+ 0.00 / - 0.72
(Equiv. 7.953 in.)
Approx. Loose Circlip ID (A)
193.00
mm
External Retaining Rings - 208x5x202 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-20800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 212x5x206 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
212.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
206.00
mm
+ 0.00 / - 0.72
(Equiv. 8.11 in.)
Approx. Loose Circlip ID (A)
198.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 212x5x206 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-21200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 212x5x206 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
212.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
206.00
mm
+ 0.00 / - 0.72
(Equiv. 8.11 in.)
Approx. Loose Circlip ID (A)
198.00
mm
External Retaining Rings - 212x5x206 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-21200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 165.1x3.96x158.1 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
165.10
mm
Clip Thickness (T)
3.96
mm
+/- 0.127
(Equiv. 0.156 in.)
Groove Dia. (Dg)
158.10
mm
+/- 0.204
(Equiv. 6.224 in.)
Approx. Loose Circlip ID (A)
154.90
mm
Groove Width (W)
4.40
mm
External Retaining Rings - 165.1x3.96x158.1 mm - Carbon Steel
Material: Carbon Steel    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 11
Part Number: CCE-16510-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$169.95 AUD
$202.35 AUD $169.95 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 165.1x3.96x158.1 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
165.10
mm
Clip Thickness (T)
3.96
mm
+/- 0.127
(Equiv. 0.156 in.)
Groove Dia. (Dg)
158.10
mm
+/- 0.204
(Equiv. 6.224 in.)
Approx. Loose Circlip ID (A)
154.90
mm
External Retaining Rings - 165.1x3.96x158.1 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.40 mm    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 11
Part Number: CCE-16510-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$169.95 AUD
$202.35 AUD $169.95 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 217x5x211 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
217.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
211.00
mm
+ 0.00 / - 0.72
(Equiv. 8.307 in.)
Approx. Loose Circlip ID (A)
203.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 217x5x211 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-21700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 217x5x211 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
217.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
211.00
mm
+ 0.00 / - 0.72
(Equiv. 8.307 in.)
Approx. Loose Circlip ID (A)
203.00
mm
External Retaining Rings - 217x5x211 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-21700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 218x5x212 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
218.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
212.00
mm
+ 0.00 / - 0.72
(Equiv. 8.346 in.)
Approx. Loose Circlip ID (A)
203.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 218x5x212 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-21800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 218x5x212 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
218.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
212.00
mm
+ 0.00 / - 0.72
(Equiv. 8.346 in.)
Approx. Loose Circlip ID (A)
203.00
mm
External Retaining Rings - 218x5x212 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-21800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 170x4x165 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
170.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
165.00
mm
+ 0.00 / - 0.63
(Equiv. 6.496 in.)
Approx. Loose Circlip ID (A)
160.50
mm
Groove Width (W)
4.15
mm
External Retaining Rings - 170x4x165 mm - Carbon Steel
Material: Carbon Steel    Clearance on Shaft (C1): 192.00 mm    Clearance in Groove (C1): 198.40 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Additional stock available from USA subject to Prior Sale = 30
Part Number: CCE-17000-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$27.86 AUD
$32.44 AUD $27.86 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 170x4x165 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
170.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
165.00
mm
+ 0.00 / - 0.63
(Equiv. 6.496 in.)
Approx. Loose Circlip ID (A)
160.50
mm
External Retaining Rings - 170x4x165 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.15 mm    Clearance on Shaft (C1): 192.00 mm    Clearance in Groove (C1): 198.40 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Additional stock available from USA subject to Prior Sale = 30
Part Number: CCE-17000-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$27.86 AUD
$32.44 AUD $27.86 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 222x5x216 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
222.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
216.00
mm
+ 0.00 / - 0.72
(Equiv. 8.504 in.)
Approx. Loose Circlip ID (A)
208.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 222x5x216 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-22200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 222x5x216 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
222.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
216.00
mm
+ 0.00 / - 0.72
(Equiv. 8.504 in.)
Approx. Loose Circlip ID (A)
208.00
mm
External Retaining Rings - 222x5x216 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-22200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 225x5x219 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
225.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
219.00
mm
+ 0.00 / - 0.72
(Equiv. 8.622 in.)
Approx. Loose Circlip ID (A)
213.72
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 225x5x219 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Min. Lug Diameter (h): 4.000 mm    Standard: DIN471
Part Number: CCE-22500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 225x5x219 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
225.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
219.00
mm
+ 0.00 / - 0.72
(Equiv. 8.622 in.)
Approx. Loose Circlip ID (A)
213.72
mm
External Retaining Rings - 225x5x219 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Min. Lug Diameter (h): 4.000 mm    Standard: DIN471
Part Number: CCE-22500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 227x5x221 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
227.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
221.00
mm
+ 0.00 / - 0.72
(Equiv. 8.701 in.)
Approx. Loose Circlip ID (A)
213.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 227x5x221 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-22700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 227x5x221 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
227.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
221.00
mm
+ 0.00 / - 0.72
(Equiv. 8.701 in.)
Approx. Loose Circlip ID (A)
213.00
mm
External Retaining Rings - 227x5x221 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-22700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 171.45x3.96x164.2 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
171.45
mm
Clip Thickness (T)
3.96
mm
+/- 0.127
(Equiv. 0.156 in.)
Groove Dia. (Dg)
164.20
mm
+/- 0.204
(Equiv. 6.465 in.)
Approx. Loose Circlip ID (A)
160.90
mm
Groove Width (W)
4.40
mm
External Retaining Rings - 171.45x3.96x164.2 mm - Carbon Steel
Material: Carbon Steel    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 3
Part Number: CCE-17145-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$177.23 AUD
$211.07 AUD $177.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 171.45x3.96x164.2 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
171.45
mm
Clip Thickness (T)
3.96
mm
+/- 0.127
(Equiv. 0.156 in.)
Groove Dia. (Dg)
164.20
mm
+/- 0.204
(Equiv. 6.465 in.)
Approx. Loose Circlip ID (A)
160.90
mm
External Retaining Rings - 171.45x3.96x164.2 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.40 mm    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 3
Part Number: CCE-17145-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$177.23 AUD
$211.07 AUD $177.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 228x5x222 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
228.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
222.00
mm
+ 0.00 / - 0.72
(Equiv. 8.74 in.)
Approx. Loose Circlip ID (A)
213.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 228x5x222 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-22800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 228x5x222 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
228.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
222.00
mm
+ 0.00 / - 0.72
(Equiv. 8.74 in.)
Approx. Loose Circlip ID (A)
213.00
mm
External Retaining Rings - 228x5x222 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-22800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 175x4x169.37 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
175.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
169.37
mm
+ 0.00 / - 0.63
(Equiv. 6.668 in.)
Approx. Loose Circlip ID (A)
166.13
mm
Groove Width (W)
4.15
mm
External Retaining Rings - 175x4x169.37 mm - Carbon Steel
Material: Carbon Steel    Clearance on Shaft (C1): 197.00 mm    Clearance in Groove (C1): 203.40 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Additional stock available from USA subject to Prior Sale = 10
Part Number: CCE-17500-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$29.14 AUD
$33.96 AUD $29.14 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 175x4x169.37 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
175.00
mm
Clip Thickness (T)
4.00
mm
+ 0.00 / - 0.10
(Equiv. 0.157 in.)
Groove Dia. (Dg)
169.37
mm
+ 0.00 / - 0.63
(Equiv. 6.668 in.)
Approx. Loose Circlip ID (A)
166.13
mm
External Retaining Rings - 175x4x169.37 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.15 mm    Clearance on Shaft (C1): 197.00 mm    Clearance in Groove (C1): 203.40 mm    Min. Lug Diameter (h): 4.00 mm    Min. Extension (n): 7.50    Standard: DIN471
Additional stock available from USA subject to Prior Sale = 10
Part Number: CCE-17500-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$29.14 AUD
$33.96 AUD $29.14 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 232x5x226 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
232.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
226.00
mm
+ 0.00 / - 0.72
(Equiv. 8.898 in.)
Approx. Loose Circlip ID (A)
218.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 232x5x226 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-23200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 232x5x226 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
232.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
226.00
mm
+ 0.00 / - 0.72
(Equiv. 8.898 in.)
Approx. Loose Circlip ID (A)
218.00
mm
External Retaining Rings - 232x5x226 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-23200-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 235x5x229 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
235.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
229.00
mm
+ 0.00 / - 0.72
(Equiv. 9.016 in.)
Approx. Loose Circlip ID (A)
223.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 235x5x229 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-23500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 235x5x229 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
235.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
229.00
mm
+ 0.00 / - 0.72
(Equiv. 9.016 in.)
Approx. Loose Circlip ID (A)
223.00
mm
External Retaining Rings - 235x5x229 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-23500-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 177.8x4x170.3 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
177.80
mm
Clip Thickness (T)
4.00
mm
+/- 0.127
(Equiv. 0.157 in.)
Groove Dia. (Dg)
170.30
mm
+/- 0.204
(Equiv. 6.705 in.)
Approx. Loose Circlip ID (A)
166.90
mm
Groove Width (W)
4.40
mm
External Retaining Rings - 177.8x4x170.3 mm - Carbon Steel
Material: Carbon Steel    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 3
Part Number: CCE-17780-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$182.50 AUD
$217.40 AUD $182.50 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 177.8x4x170.3 mm Circlips - Carbon Steel Circlip
Shaft Diameter (Ds)
177.80
mm
Clip Thickness (T)
4.00
mm
+/- 0.127
(Equiv. 0.157 in.)
Groove Dia. (Dg)
170.30
mm
+/- 0.204
(Equiv. 6.705 in.)
Approx. Loose Circlip ID (A)
166.90
mm
External Retaining Rings - 177.8x4x170.3 mm - Carbon Steel
Material: Carbon Steel    Groove Width (W): 4.40 mm    Standard: MIL-16624
Additional stock available from USA subject to Prior Sale = 3
Part Number: CCE-17780-C (Each)
Out of Stock | Backorder Now | Backorder now for delivery around Wed, Aug 26, 2026
$182.50 AUD
$217.40 AUD $182.50 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
External Retaining Rings - 237x5x231 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
237.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
231.00
mm
+ 0.00 / - 0.72
(Equiv. 9.094 in.)
Approx. Loose Circlip ID (A)
223.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 237x5x231 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-23700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 237x5x231 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
237.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
231.00
mm
+ 0.00 / - 0.72
(Equiv. 9.094 in.)
Approx. Loose Circlip ID (A)
223.00
mm
External Retaining Rings - 237x5x231 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-23700-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
External Retaining Rings - 238x5x232 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
238.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
232.00
mm
+ 0.00 / - 0.72
(Equiv. 9.134 in.)
Approx. Loose Circlip ID (A)
223.00
mm
Groove Width (W)
5.15
mm
External Retaining Rings - 238x5x232 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Standard: DIN471
Part Number: CCE-23800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
External Retaining Rings - 238x5x232 mm Circlips - Carbon Spring Steel Self Finish Circlip
Shaft Diameter (Ds)
238.00
mm
Clip Thickness (T)
5.00
mm
+ 0.00 / - 0.12
(Equiv. 0.197 in.)
Groove Dia. (Dg)
232.00
mm
+ 0.00 / - 0.72
(Equiv. 9.134 in.)
Approx. Loose Circlip ID (A)
223.00
mm
External Retaining Rings - 238x5x232 mm - Carbon Spring Steel Self Finish
Material: Carbon Spring Steel Self Finish    Groove Width (W): 5.15 mm    Standard: DIN471
Part Number: CCE-23800-C (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Mon, Apr 23, 2029
