Collection: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide

Pulleys (With Images)

Metric Timing

3.000mm Pitch

HTD

6mm Wide
9mm Wide

208 Products in this selection

This is a combined category of 9mm Wide HTD 3.000mm Pitch Metric Timing Pulleys.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Timing Pulleys Catalogue PDF
3mm HTD Timing Belts

A more concise listing may be found on the Smallparts store at Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide. Smallparts promote the most popular MBA products.

Teeth	Max Belt Width	Bore (d)	Bore Type	Locking Type	Indicative Image
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 3.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-030 Metric Timing Pulleys - 10 tooth - 9x3 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.50 AUD Regular price Sale price $42.50 AUD Unit price per Each
Teeth	Max Belt Width	Bore (d)	Bore Type	Indicative Image
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 3.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-030 Metric Timing Pulleys - 10 tooth - 9x3 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.50 AUD Regular price Sale price $42.50 AUD Unit price per Each View the product page first if you are unsure.
P-030H-010-090FH-AL-G-030 --- Metric Timing Pulleys - 10 tooth - 9x3 mm - Aluminium P-030H-010-090FH-AL-G-030 --- Metric Timing Pulleys - 10 tooth - 9x3 mm - Aluminium Regular price $42.50 AUD Regular price Sale price $42.50 AUD Unit price per Out of stock! Backorder Now
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 3.175 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-032 Metric Timing Pulleys - 10 tooth - 9x3.175 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Each
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 3.175 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-032 Metric Timing Pulleys - 10 tooth - 9x3.175 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Each View the product page first if you are unsure.
P-030H-010-090FH-AL-G-032 --- Metric Timing Pulleys - 10 tooth - 9x3.175 mm - Aluminium P-030H-010-090FH-AL-G-032 --- Metric Timing Pulleys - 10 tooth - 9x3.175 mm - Aluminium Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Out of stock! Backorder Now
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-048 Metric Timing Pulleys - 10 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Each
Teeth 10	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 9.55 mm Flange Diameter (FD): 12.8 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-010-090FH-AL-G-048 Metric Timing Pulleys - 10 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Each View the product page first if you are unsure.
P-030H-010-090FH-AL-G-048 --- Metric Timing Pulleys - 10 tooth - 9x4.763 mm - Aluminium P-030H-010-090FH-AL-G-048 --- Metric Timing Pulleys - 10 tooth - 9x4.763 mm - Aluminium Regular price $42.41 AUD Regular price Sale price $42.41 AUD Unit price per Out of stock! Backorder Now
Teeth 11	Max Belt Width 9.00 mm	Bore (d) 3.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 10.50 mm Flange Diameter (FD): 13.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-011-090FH-AL-G-030 Metric Timing Pulleys - 11 tooth - 9x3 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.59 AUD Regular price Sale price $42.59 AUD Unit price per Each
Teeth 11	Max Belt Width 9.00 mm	Bore (d) 3.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 10.50 mm Flange Diameter (FD): 13.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-011-090FH-AL-G-030 Metric Timing Pulleys - 11 tooth - 9x3 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.59 AUD Regular price Sale price $42.59 AUD Unit price per Each View the product page first if you are unsure.
P-030H-011-090FH-AL-G-030 --- Metric Timing Pulleys - 11 tooth - 9x3 mm - Aluminium P-030H-011-090FH-AL-G-030 --- Metric Timing Pulleys - 11 tooth - 9x3 mm - Aluminium Regular price $42.59 AUD Regular price Sale price $42.59 AUD Unit price per Out of stock! Backorder Now
Teeth 11	Max Belt Width 9.00 mm	Bore (d) 3.175 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 10.50 mm Flange Diameter (FD): 13.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-011-090FH-AL-G-032 Metric Timing Pulleys - 11 tooth - 9x3.175 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.68 AUD Regular price Sale price $42.68 AUD Unit price per Each
Teeth 11	Max Belt Width 9.00 mm	Bore (d) 3.175 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 10.50 mm Flange Diameter (FD): 13.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-011-090FH-AL-G-032 Metric Timing Pulleys - 11 tooth - 9x3.175 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.68 AUD Regular price Sale price $42.68 AUD Unit price per Each View the product page first if you are unsure.
P-030H-011-090FH-AL-G-032 --- Metric Timing Pulleys - 11 tooth - 9x3.175 mm - Aluminium P-030H-011-090FH-AL-G-032 --- Metric Timing Pulleys - 11 tooth - 9x3.175 mm - Aluminium Regular price $42.68 AUD Regular price Sale price $42.68 AUD Unit price per Out of stock! Backorder Now
Teeth 12	Max Belt Width 9.00 mm	Bore (d) 4.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-012-090FH-AL-G-040 Metric Timing Pulleys - 12 tooth - 9x4 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.95 AUD Regular price Sale price $42.95 AUD Unit price per Each
Teeth 12	Max Belt Width 9.00 mm	Bore (d) 4.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-012-090FH-AL-G-040 Metric Timing Pulleys - 12 tooth - 9x4 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.95 AUD Regular price Sale price $42.95 AUD Unit price per Each View the product page first if you are unsure.
P-030H-012-090FH-AL-G-040 --- Metric Timing Pulleys - 12 tooth - 9x4 mm - Aluminium P-030H-012-090FH-AL-G-040 --- Metric Timing Pulleys - 12 tooth - 9x4 mm - Aluminium Regular price $42.95 AUD Regular price Sale price $42.95 AUD Unit price per Out of stock! Backorder Now
Teeth 12	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-012-090FH-AL-G-048 Metric Timing Pulleys - 12 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.14 AUD Regular price Sale price $43.14 AUD Unit price per Each
Teeth 12	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 1 Pitch Dia. (PD): 11.45 mm Flange Diameter (FD): 14.7 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-012-090FH-AL-G-048 Metric Timing Pulleys - 12 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.14 AUD Regular price Sale price $43.14 AUD Unit price per Each View the product page first if you are unsure.
P-030H-012-090FH-AL-G-048 --- Metric Timing Pulleys - 12 tooth - 9x4.763 mm - Aluminium P-030H-012-090FH-AL-G-048 --- Metric Timing Pulleys - 12 tooth - 9x4.763 mm - Aluminium Regular price $43.14 AUD Regular price Sale price $43.14 AUD Unit price per Out of stock! Backorder Now
Teeth 13	Max Belt Width 9.00 mm	Bore (d) 4.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-013-090FF-AL-G-040 Metric Timing Pulleys - 13 tooth - 9x4 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Each
Teeth 13	Max Belt Width 9.00 mm	Bore (d) 4.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-013-090FF-AL-G-040 Metric Timing Pulleys - 13 tooth - 9x4 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Each View the product page first if you are unsure.
P-030H-013-090FF-AL-G-040 --- Metric Timing Pulleys - 13 tooth - 9x4 mm - Aluminium P-030H-013-090FF-AL-G-040 --- Metric Timing Pulleys - 13 tooth - 9x4 mm - Aluminium Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Out of stock! Backorder Now
Teeth 13	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-013-090FF-AL-G-048 Metric Timing Pulleys - 13 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per Each
Teeth 13	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 12.41 mm Flange Diameter (FD): 15.5 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-013-090FF-AL-G-048 Metric Timing Pulleys - 13 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per Each View the product page first if you are unsure.
P-030H-013-090FF-AL-G-048 --- Metric Timing Pulleys - 13 tooth - 9x4.763 mm - Aluminium P-030H-013-090FF-AL-G-048 --- Metric Timing Pulleys - 13 tooth - 9x4.763 mm - Aluminium Regular price $43.32 AUD Regular price Sale price $43.32 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-048 Metric Timing Pulleys - 14 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.77 AUD Regular price Sale price $43.77 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-048 Metric Timing Pulleys - 14 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.77 AUD Regular price Sale price $43.77 AUD Unit price per Each View the product page first if you are unsure.
P-030H-014-090FF-AL-G-048 --- Metric Timing Pulleys - 14 tooth - 9x4.763 mm - Aluminium P-030H-014-090FF-AL-G-048 --- Metric Timing Pulleys - 14 tooth - 9x4.763 mm - Aluminium Regular price $43.77 AUD Regular price Sale price $43.77 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 5.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: 1 Pitch Dia. (PD): 13.37 mm Flange Diameter (FD): 16.00 mm Overall Length: 23.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FH-AL-G-050 Metric Timing Pulleys - 14 tooth - 9x5 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $22.50 AUD Regular price Sale price $22.50 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 5.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: 1 Pitch Dia. (PD): 13.37 mm Flange Diameter (FD): 16.00 mm Overall Length: 23.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FH-AL-G-050 Metric Timing Pulleys - 14 tooth - 9x5 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $22.50 AUD Regular price Sale price $22.50 AUD Unit price per Each View the product page first if you are unsure.
P-030H-014-090FH-AL-G-050 --- Metric Timing Pulleys - 14 tooth - 9x5 mm - Aluminium P-030H-014-090FH-AL-G-050 --- Metric Timing Pulleys - 14 tooth - 9x5 mm - Aluminium Regular price $22.50 AUD Regular price Sale price $22.50 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 6.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-060 Metric Timing Pulleys - 14 tooth - 9x6 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.77 AUD Regular price Sale price $42.77 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 6.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-060 Metric Timing Pulleys - 14 tooth - 9x6 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $42.77 AUD Regular price Sale price $42.77 AUD Unit price per Each View the product page first if you are unsure.
P-030H-014-090FF-AL-G-060 --- Metric Timing Pulleys - 14 tooth - 9x6 mm - Aluminium P-030H-014-090FF-AL-G-060 --- Metric Timing Pulleys - 14 tooth - 9x6 mm - Aluminium Regular price $42.77 AUD Regular price Sale price $42.77 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 6.350 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-064 Metric Timing Pulleys - 14 tooth - 9x6.35 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 6.350 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 13.36 mm Flange Diameter (FD): 16.1 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-014-090FF-AL-G-064 Metric Timing Pulleys - 14 tooth - 9x6.35 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Each View the product page first if you are unsure.
P-030H-014-090FF-AL-G-064 --- Metric Timing Pulleys - 14 tooth - 9x6.35 mm - Aluminium P-030H-014-090FF-AL-G-064 --- Metric Timing Pulleys - 14 tooth - 9x6.35 mm - Aluminium Regular price $43.68 AUD Regular price Sale price $43.68 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hub Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Overall Length: 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-AL-G-080 Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $22.77 AUD Regular price Sale price $22.77 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hub Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Overall Length: 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-AL-G-080 Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $22.77 AUD Regular price Sale price $22.77 AUD Unit price per Each View the product page first if you are unsure.
P-050H-014-090FF-AL-G-080 --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium P-050H-014-090FF-AL-G-080 --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Regular price $22.77 AUD Regular price Sale price $22.77 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-080 Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-080 Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each View the product page first if you are unsure.
P-050H-014-090FF-ALN-G-080 --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium P-050H-014-090FF-ALN-G-080 --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 10.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-100 Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 10.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-100 Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each View the product page first if you are unsure.
P-050H-014-090FF-ALN-G-100 --- Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium P-050H-014-090FF-ALN-G-100 --- Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Keyed	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-080K Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Keyed
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-080K Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Each View the product page first if you are unsure.
P-050H-014-090FF-ALN-G-080K --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium P-050H-014-090FF-ALN-G-080K --- Metric Timing Pulleys - 14 tooth - 9x8 mm - Aluminium Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Out of stock! Backorder Now
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 10.000 mm	Bore Type Keyed	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-100K Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Each
Teeth 14	Max Belt Width 9.00 mm	Bore (d) 10.000 mm	Bore Type Keyed
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 22.28 mm Flange Diameter (FD): 26.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-014-090FF-ALN-G-100K Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Each View the product page first if you are unsure.
P-050H-014-090FF-ALN-G-100K --- Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium P-050H-014-090FF-ALN-G-100K --- Metric Timing Pulleys - 14 tooth - 9x10 mm - Aluminium Regular price $23.50 AUD Regular price Sale price $23.50 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FF-AL-G-048 Metric Timing Pulleys - 15 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $44.23 AUD Regular price Sale price $44.23 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 4.763 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FF-AL-G-048 Metric Timing Pulleys - 15 tooth - 9x4.763 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $44.23 AUD Regular price Sale price $44.23 AUD Unit price per Each View the product page first if you are unsure.
P-030H-015-090FF-AL-G-048 --- Metric Timing Pulleys - 15 tooth - 9x4.763 mm - Aluminium P-030H-015-090FF-AL-G-048 --- Metric Timing Pulleys - 15 tooth - 9x4.763 mm - Aluminium Regular price $44.23 AUD Regular price Sale price $44.23 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 5.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: 1 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 18.00 mm Overall Length: 23.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FH-AL-G-050 Metric Timing Pulleys - 15 tooth - 9x5 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 5.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: 1 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 18.00 mm Overall Length: 23.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FH-AL-G-050 Metric Timing Pulleys - 15 tooth - 9x5 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Each View the product page first if you are unsure.
P-030H-015-090FH-AL-G-050 --- Metric Timing Pulleys - 15 tooth - 9x5 mm - Aluminium P-030H-015-090FH-AL-G-050 --- Metric Timing Pulleys - 15 tooth - 9x5 mm - Aluminium Regular price $23.23 AUD Regular price Sale price $23.23 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 6.000 mm	Bore Type Finished	Locking Type Set Screw
Material: Aluminium Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FF-AL-G-060 Metric Timing Pulleys - 15 tooth - 9x6 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.23 AUD Regular price Sale price $43.23 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 6.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screw Type: 2 Pitch Dia. (PD): 14.32 mm Flange Diameter (FD): 17.4 mm Overall Length: 17.5 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-030H-015-090FF-AL-G-060 Metric Timing Pulleys - 15 tooth - 9x6 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 27, 2025 Regular price $43.23 AUD Regular price Sale price $43.23 AUD Unit price per Each View the product page first if you are unsure.
P-030H-015-090FF-AL-G-060 --- Metric Timing Pulleys - 15 tooth - 9x6 mm - Aluminium P-030H-015-090FF-AL-G-060 --- Metric Timing Pulleys - 15 tooth - 9x6 mm - Aluminium Regular price $43.23 AUD Regular price Sale price $43.23 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-ALN-G-080 Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.68 AUD Regular price Sale price $23.68 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-ALN-G-080 Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.68 AUD Regular price Sale price $23.68 AUD Unit price per Each View the product page first if you are unsure.
P-050H-015-090FF-ALN-G-080 --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium P-050H-015-090FF-ALN-G-080 --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Regular price $23.68 AUD Regular price Sale price $23.68 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hub Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Overall Length: 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-AL-G-080 Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.41 AUD Regular price Sale price $23.41 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Finished
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hub Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Overall Length: 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-AL-G-080 Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.41 AUD Regular price Sale price $23.41 AUD Unit price per Each View the product page first if you are unsure.
P-050H-015-090FF-AL-G-080 --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium P-050H-015-090FF-AL-G-080 --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Regular price $23.41 AUD Regular price Sale price $23.41 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Keyed	Locking Type Set Screws
Material: Aluminium Type: Double Flanged - Hubless Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-ALN-G-080K Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.95 AUD Regular price Sale price $23.95 AUD Unit price per Each
Teeth 15	Max Belt Width 9.00 mm	Bore (d) 8.000 mm	Bore Type Keyed
Material: Aluminium Locking Type: Set Screws Type: Double Flanged - Hubless Pitch Dia. (PD): 23.87 mm Flange Diameter (FD): 28.00 mm Category: Pulleys - Metric Timing - 3.000mm Pitch - HTD - 9mm Wide - Metallic
Part Number: P-050H-015-090FF-ALN-G-080K Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Out of Stock \| Backorder Now \| Orders can be expected around Fri, Jun 13, 2025 Regular price $23.95 AUD Regular price Sale price $23.95 AUD Unit price per Each View the product page first if you are unsure.
P-050H-015-090FF-ALN-G-080K --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium P-050H-015-090FF-ALN-G-080K --- Metric Timing Pulleys - 15 tooth - 9x8 mm - Aluminium Regular price $23.95 AUD Regular price Sale price $23.95 AUD Unit price per Out of stock! Backorder Now
