Bearings - Tapered Roller Cup

5 Products in this selection
  • Replacements for existing tapered roller cups (outer part). Match with part number on your existing bearing. It is recommended that you change both cup and cone whenever possible.
Additional resources:
A more concise listing may be found on the Smallparts store at Bearings - Tapered Roller Cup. Smallparts promote the most popular MBA products.
Outside Diameter Cup Width Matching Cones rs1 min rs2 min Indicative
Outside Diameter
49.225
mm

(1.938 in.)
Cup Width
17.462
mm

(0.687 in.)
Matching Cones
09067, 09074, 09078
rs1 min
1.300
mm
rs2 min
1.500
mm
1159316 | 09196 --- Tapered Roller Cup Bearings - 49.225x17.462 mm - 09067, 09074, 09078 - Chrome Steel
Material: Chrome Steel    Basic Dynamic Load Rating: 37500 Cr (N)    Basic Static Load Rating: 37500 Cor (N)    Limiting Speed with Grease: 8500 RPM
Part Number: 09196 Tapered Roller Cup Bearings - 49.225x17.462 mm - 09067, 09074, 09078 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$25.14 AUD
$25.14 AUD
Each
Outside Diameter Cup Width Matching Cones Indicative
Outside Diameter
49.225
mm

(1.938 in.)
Cup Width
17.462
mm

(0.687 in.)
Matching Cones
09067, 09074, 09078
1159316 | 09196 --- Tapered Roller Cup Bearings - 49.225x17.462 mm - 09067, 09074, 09078 - Chrome Steel
Material: Chrome Steel    rs1 min: 1.300 mm    rs2 min: 1.500 mm    Basic Dynamic Load Rating: 37500 Cr (N)    Basic Static Load Rating: 37500 Cor (N)    Limiting Speed with Grease: 8500 RPM
Part Number: 09196 Tapered Roller Cup Bearings - 49.225x17.462 mm - 09067, 09074, 09078 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$25.14 AUD
$25.14 AUD
Each
View the product page first if you are unsure.
Outside Diameter
93.264
mm

(3.672 in.)
Cup Width
23.812
mm

(0.937 in.)
rs1 min
3.500
mm
rs2 min
3.300
mm
1183319 | 3720 --- Tapered Roller Cup Bearings - 93.264x23.812 mm - Chrome Steel
Material: Chrome Steel    Basic Dynamic Load Rating: 102000 Cr (N)    Basic Static Load Rating: 134000 Cor (N)    Limiting Speed with Grease: 3800 RPM
Part Number: 3720 Tapered Roller Cup Bearings - 93.264x23.812 mm - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$36.05 AUD
$36.05 AUD
Each
Outside Diameter
93.264
mm

(3.672 in.)
Cup Width
23.812
mm

(0.937 in.)
1183319 | 3720 --- Tapered Roller Cup Bearings - 93.264x23.812 mm - Chrome Steel
Material: Chrome Steel    rs1 min: 3.500 mm    rs2 min: 3.300 mm    Basic Dynamic Load Rating: 102000 Cr (N)    Basic Static Load Rating: 134000 Cor (N)    Limiting Speed with Grease: 3800 RPM
Part Number: 3720 Tapered Roller Cup Bearings - 93.264x23.812 mm - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$36.05 AUD
$36.05 AUD
Each
View the product page first if you are unsure.
Outside Diameter
122.238
mm

(4.813 in.)
Cup Width
29.718
mm

(1.17 in.)
Matching Cones
HM212047
rs1 min
7.000
mm
rs2 min
3.300
mm
1192803 | HM212011 --- Tapered Roller Cup Bearings - 122.238x29.718 mm - HM212047 - Chrome Steel
Material: Chrome Steel    Basic Dynamic Load Rating: 187000 Cr (N)    Basic Static Load Rating: 243000 Cor (N)    Limiting Speed with Grease: 3000 RPM
Part Number: HM212011 Tapered Roller Cup Bearings - 122.238x29.718 mm - HM212047 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$55.32 AUD
$55.32 AUD
Each
Outside Diameter
122.238
mm

(4.813 in.)
Cup Width
29.718
mm

(1.17 in.)
Matching Cones
HM212047
1192803 | HM212011 --- Tapered Roller Cup Bearings - 122.238x29.718 mm - HM212047 - Chrome Steel
Material: Chrome Steel    rs1 min: 7.000 mm    rs2 min: 3.300 mm    Basic Dynamic Load Rating: 187000 Cr (N)    Basic Static Load Rating: 243000 Cor (N)    Limiting Speed with Grease: 3000 RPM
Part Number: HM212011 Tapered Roller Cup Bearings - 122.238x29.718 mm - HM212047 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$55.32 AUD
$55.32 AUD
Each
View the product page first if you are unsure.
Outside Diameter
146.050
mm

(5.75 in.)
Cup Width
31.750
mm

(1.25 in.)
Matching Cones
655, 661, 663
rs1 min
3.500
mm
rs2 min
3.300
mm
Tapered Roller Cup Bearings - 146.05x31.75 mm - 655, 661, 663 - Chrome Steel
Material: Chrome Steel    Basic Dynamic Load Rating: 188000 Cr (N)    Basic Static Load Rating: 260000 Cor (N)    Limiting Speed with Grease: 2500 RPM
Part Number: 653 Tapered Roller Cup Bearings - 146.05x31.75 mm - 655, 661, 663 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$90.50 AUD
$90.50 AUD
Each
Outside Diameter
146.050
mm

(5.75 in.)
Cup Width
31.750
mm

(1.25 in.)
Matching Cones
655, 661, 663
Tapered Roller Cup Bearings - 146.05x31.75 mm - 655, 661, 663 - Chrome Steel
Material: Chrome Steel    rs1 min: 3.500 mm    rs2 min: 3.300 mm    Basic Dynamic Load Rating: 188000 Cr (N)    Basic Static Load Rating: 260000 Cor (N)    Limiting Speed with Grease: 2500 RPM
Part Number: 653 Tapered Roller Cup Bearings - 146.05x31.75 mm - 655, 661, 663 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$90.50 AUD
$90.50 AUD
Each
View the product page first if you are unsure.
Outside Diameter
147.000
mm

(5.787 in.)
Cup Width
32.500
mm

(1.28 in.)
Matching Cones
HM218248
rs1 min
7.000
mm
rs2 min
3.500
mm
1198317 | HM218210 --- Tapered Roller Cup Bearings - 147x32.5 mm - HM218248 - Chrome Steel
Material: Chrome Steel    Basic Dynamic Load Rating: 220000 Cr (N)    Basic Static Load Rating: 325000 Cor (N)    Limiting Speed with Grease: 2300 RPM
Part Number: HM218210 Tapered Roller Cup Bearings - 147x32.5 mm - HM218248 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$77.14 AUD
$77.14 AUD
Each
Outside Diameter
147.000
mm

(5.787 in.)
Cup Width
32.500
mm

(1.28 in.)
Matching Cones
HM218248
1198317 | HM218210 --- Tapered Roller Cup Bearings - 147x32.5 mm - HM218248 - Chrome Steel
Material: Chrome Steel    rs1 min: 7.000 mm    rs2 min: 3.500 mm    Basic Dynamic Load Rating: 220000 Cr (N)    Basic Static Load Rating: 325000 Cor (N)    Limiting Speed with Grease: 2300 RPM
Part Number: HM218210 Tapered Roller Cup Bearings - 147x32.5 mm - HM218248 - Chrome Steel
Out of Stock | Backorder Now | Orders can be expected around Tue, May 20, 2025
$77.14 AUD
$77.14 AUD
Each
View the product page first if you are unsure.
